Product Information ■ Model Number: TS-V174S
■ Playback Method: Coaxial 2-way
■ Speaker Specifications: Woofer: φ170mm diameter, water-resistant speaker, two-layer "aramid fiber cone", corrugated edge, 330g strontium magnet; Tweeter: φ29mm balanced dome tweeter, aluminum alloy diaphragm, polyurethane-coated edge, special heat-resistant voice coil, magnetic fluid used (magnetic circuit), 3g neodymium magnet
■ Impedance (Network Connection): 4Ω
■ Output Sound Pressure Level: 91dB
■ Playback Frequency Range: 33Hz - 64000Hz
■ Maximum Instantaneous Input Power: 180W
■ Rated Input Power: 50W
■ Weight (1 unit including accessories): 1.09kg
■ Total Weight (2 units including packaging): 2.50kg
■ "Open & The "Open & Smooth" concept delivers an open soundscape and realistic midrange, reproducing all musical content as it is. Delivering a musical experience beyond imagination.
■ The "Open & Smooth" concept reproduces midrange frequencies from the highly directional tweeter, achieving excellent directivity. A low crossover design, taking into account the effects of directivity, ensures a smooth connection with the woofer, delivering sound that is ideal for the vehicle cabin.
■ The speaker employs a titanium balanced dome diaphragm with wide directivity, high Young's modulus, and low internal loss. Pioneer's proprietary, advanced optimization method is used for the diaphragm, reproducing even the ultra-high frequencies.
■ The "vertex drive system" minimizes transmission loss to the diaphragm, thoroughly eliminating unwanted resonance. The neodymium magnet provides powerful magnetic flux and improved transient response.
■ A new circuit board with a new pattern has been developed for the woofer network, enabling a simpler configuration and eliminating the need for compensation resistors. A similar new circuit board has been developed for the tweeter network. The design has been further refined to further reduce noise. It also features an attenuator that allows for three-stage tweeter sensitivity adjustment. The woofer's rear frame employs a truss structure. While achieving high strength, the frame's volume has been significantly reduced, improving sound projection. This achieves both aesthetic beauty and functionality. Even in limited spaces, the same ease of installation as before has been ensured, and the design has been optimized down to the finest detail to achieve improved sound quality. *Depending on the vehicle model and grade, or if a premium audio system is installed as a special feature or option, you may need to check the installation information. *To prevent accidents, please pay close attention to the location and method of fixing the tweeter when installing it. For details, please consult your dealer or refer to the vehicle-specific information on the Pioneer website's "Carrozzeria JUST FIT Web." *Due to product specifications, a connecting cord is not included with the TS-V174S; therefore, a separate cord must be installed. Accessories: Screws (Φ4mm x 18mm) x 8, Screws (Φ5mm x 18mm) x 8, Washers (Φ12mm x φ5.5mm) x 8, Double-sided adhesive tape (2 types of thickness) x 2, Cross-recessed low-head screws (Φ4mm x 14mm) x 2, Cross-recessed low-head screws (Φ3mm x 7mm) x 2, Screws (Φ3mm x 25mm) x 8, Anti-vibration gasket, Mounting brackets x 2, L-shaped brackets x 2, Distribution cords x 2, Flat terminals (large) x 2, Flat terminal sleeves (large) x 2, Flat terminals (small) x 2, Flat terminal sleeves (small) x 2, Screws (M5mm x 25mm) x 2, Nuts x 2. *This product will be shipped from the manufacturer upon receiving your order. *We do not accept cancellations, exchanges, or returns after an order has been placed. *After placing your order, we may be unable to meet your desired delivery date or may have to decline your order due to reasons such as "out of stock," "discontinued production," or "delivery date undecided." Please note.

---
