Product Information: ■ Model Number: TS-C1740S
■ Playback Method: Coaxial 2-way
■ Speaker Specifications: Woofer: φ170mm diameter, water-resistant speaker, two-layer "aramid fiber cone", corrugated edge, 330g strontium magnet; Tweeter: φ29mm balanced dome tweeter, aluminum alloy diaphragm, polyurethane-coated edge, special heat-resistant voice coil, 6g neodymium magnet
■ Impedance (Network Connection): 4Ω
■ Output Sound Pressure Level: 90dB
■ Playback Frequency Range: 33Hz - 64000Hz
■ Maximum Instantaneous Input Power: 180W
■ Rated Input Power: 50W
■ Weight (1 unit including accessories): 1.20kg
■ Total Weight (2 units including packaging): 2.70kg
■ Delivers clear, deep, and balanced sound. The immersive vocals and crisp bass lines create a musical experience that makes you feel like you're at a live concert. Based on the "Open & Smooth" concept, these speakers achieve clear sound image positioning and a immersive sound field. They even reproduce lingering sound and reflected sound to express the spaciousness and presence of the sound field, even the artist's movements. The meticulous design evokes a vibrant and immersive musical experience. The speakers deliver powerful bass and clear midrange sounds with minimal distortion, creating a dynamic sound. The highly rigid diaphragm responds accurately to the input signal. The reduced sound distortion enhances the bass and clarity of the midrange. The newly developed "truss basket frame" enhances frame rigidity, suppressing magnetic circuit reaction and eliminating unnecessary vibrations. This delivers crisp, clear mid- and low-range sound. The highly efficient magnetic circuit, featuring a high-efficiency long voice coil, a large ferrite magnet, and an optimized yoke shape, drives the diaphragm more efficiently. Achieves low distortion and improved sonic accuracy even at high amplitudes. ■ The two-layer corrugated edge uses a new, lightweight, and durable material without any damping agents. The optimized shape achieves faster, more accurate strokes and prevents resonance at the edge, delivering high-quality sound even at high volumes. ■ To fill the vehicle interior with clear, lustrous sound, the diaphragm, magnetic circuit, and frame are specifically designed for the "C Series." Drawing on years of speaker-making expertise, the design delivers low distortion, excellent directional characteristics, and high resolution for clarity and extended high frequencies. ■ The woofer's rear frame employs a truss structure for superior strength. The widening design from the magnet to the cone visually enhances the sound's realism, achieving both performance and aesthetics. ■ The tweeter features a seamless, rounded shape with a subdued matte black finish. The design is carefully considered for visibility from the front, blending naturally into the dashboard without being overly obtrusive. ■Includes a bracket that can be attached to the factory tweeter position for 23 Toyota models, 8 Nissan models, 26 Honda models, 12 Mitsubishi models, 6 Subaru models, and 13 Suzuki models. ■Includes a "conversion connector" that allows for smooth connection between the factory speaker wiring and the woofer, and a "one-touch connection adapter" that allows for connectors of different manufacturers to be used with a single adapter. Included accessories: For woofer/network: 8 screws (Φ4mm x 18mm), 8 screws (Φ5mm x 18mm), 8 washers (Φ12mm x φ5.5mm), thick vibration-proof gasket, 2 conversion connectors, 2 connection adapters, 2 cushions (for connection adapter), 2 jumper connectors, 2 network connectors, 2 cushions (for network), cushion, 4 lock ties, 2 Carrozzeria badges, 2 double-sided tape, 2 screws (M5mm x 25mm) x 2, Nuts x 2, Tweeter Mounting Brackets (Rotary Spacer and Tweeter Unit Fixing) x 2, Cushions (Thin) x 2, Cushions (Thick, Bag-Packed) x 2, Low-Head Screws (φ4mm x 14mm) x 2, Low-Head Screws (φ3mm x 7mm) x 2, L-Shaped Brackets x 2, Cushions x 2, Tweeter Bracket-1 x 2, Tweeter Bracket-2 x 2. This product will be shipped from the manufacturer upon your order. Please note that cancellations, exchanges, and returns are not accepted after an order has been placed. Please note that we may be unable to meet your desired delivery date or may have to decline your order due to reasons such as out-of-stock, discontinued production, or undetermined delivery dates. Thank you for your understanding. Car Audio Speakers, Separate Speakers, Car, Motorcycle, Bicycle, Automotive, Car Audio, Speakers, Car Speakers. JAN/ISBN Code: 4988028523632, Product Code: 4988028523632
