The output of each A and B line pedal can be adjusted. Line
・Select
・There are 6 modes. It is useful for a variety of purposes, such as switching between amps and controlling the volume for solos and backing tracks. It can also supply power to other compact
・series pedals.
【boss_23wincam_kw】
【boss_effects_2023spr】
【】
【2107_adpt_kw】
【boss_effects_2023spr】Centralized control of a variety of settings Go to listening page (external site)FeaturesThe output of each A and B line pedal can be adjusted. Line
・Select
・There are 6 modes. It is useful for a variety of purposes, such as switching between amps and controlling the volume for solos and backing tracks. It can also supply power to other compact
・series pedals. Nominal input level: -20dBu Input impedance: 1MΩ Nominal output level: -20dBu Output impedance: 1kΩ Recommended load impedance: 10kΩ or more Bypass: Buffered Bypass controls: MODE selector switch, LEVEL knob, A/B pedal Switch indicators: CHECK indicator (also serves as battery check) Connection terminals: INPUT terminal: 1/4-inch phone type SEND terminals A/B: 1/4-inch phone type RETURN terminals A/B: 1/4-inch phone type OUTPUT terminal: 1/4-inch phone type DC IN/OUT terminals Power supply: Manganese battery (9V) or alkaline battery (9V) AC adapter (sold separately) Current consumption: 30mA Battery life during continuous use: Manganese battery: approx. 14.5 hours Alkaline battery: approx. 29.5 hours *This will vary depending on usage conditions. Accessories: Warranty leaflet (safety precautions, usage precautions, contact point), manganese battery (9V, pre-connected to the unit) Sold separately: AC adapter: PSA-100 Parallel DC cord: PCS-20A Width (W): 73 mm Depth (D): 129 mm Height (H): 59 mm Weight (including batteries): 430 g *0dBu = 0.775Vrms *Product specifications and design are subject to change without notice for improvement purposes. ■Management code: 4957054022846
