Product Information ■ Model Number: DSP-D2 [Main Unit Specifications]
■ Power Supply: DC 12V (negative ground)
■ Power Supply Voltage: 10V-15V
■ Maximum Current Consumption: 15A
■ Current Consumption: 0.35A (No Signal)
■ Fuse: 250V, 15V, Φ5.2 x 30mm (Included with Vehicle Connection Cable)
■ Remote Terminal Output for External Amplifier: 12V
■ Remote Output Current: 0.1A
■ Frequency Response (+0/-1dB): 20Hz-22kHz
■S/N Ratio: 105dB
■Total Harmonic Distortion: 0.01%
■Dimensions: W170 x D103 x H45mm
■Weight: 900g
■Vehicle Connection Harness: Approx. 2m
■Includes: DSP-equipped amplifier, vehicle connection harness, USB cable (Type A/Type B) (approx. 135cm), Velcro (2 x 10cm), instruction manual, warranty card
■For vehicles equipped with Mitsubishi genuine navigation system (20-pin)
■High-performance DSP-equipped amplifier reproduces realistic sound. Experience the immersive experience of hearing the music being played right in front of you.
■The TOON X Series comes with audio adjustment software that allows you to freely customize your sound.
■No need for complicated wiring or other modifications; simply plug and play!
■Compatible Vehicles: Mitsubishi *Please confirm compatibility before purchasing. <> Install this product in a well-ventilated location. (Recommended installation location: under the passenger seat.) Cannot be used in vehicles with factory external amplifiers. Popping noises may be heard when powering on/off, but this is not a malfunction. Reset all sound settings on the factory deck to their default settings (OFF or FLAT) before use. The factory deck's fader adjustment will no longer function. Front and rear seat independent mode cannot be used. This factory function outputs separate audio for the front and rear seats. The name of this factory function varies by manufacturer. Popping noises may occasionally occur when powering off. Setting the activation timing switch to [HIGH] may reduce the popping noise. Images are for illustrative purposes only and may differ slightly from the actual product.

---

Car Audio Sound Quality Improvement Item for Cars, Motorcycles, Bicycles, Automobiles, Car Audio, Speakers, In-Vehicle Amplifier JAN/ISBN Code: 4944799041881 Product Code: 4944799041881
